前面已经简单的介绍了拦截器的概念和每一种拦截器的作用，凭借这一点还不足以打动面试官，还需要对每一个拦截器的源码有所了解，才能够扛住面试官的各种问题！

@TOC

1.RetryAndFollowUpInterceptor

1.1 源码分析

我们知道拦截器链执行procced方法执行拦截器链中的每一个拦截器，拦截器则调用自身的intercept方法执行，所以我们只需要对intercept进行分析就可以了。

@Override  public Response intercept(Chain chain) throws IOException {     Request request = chain.request();//从拦截器链获得原始的request请求，请求信息包含了url，携带的请求体等，如果需要重定向，可能会对Request做修改更新     RealInterceptorChain realChain = (RealInterceptorChain) chain;     Call call = realChain.call();//获得call请求的原始对象，下面会用到     EventListener eventListener = realChain.eventListener(); //创建StreamAllocation对象，他主要负责分配stream，这个对象在这里创建，却没有被使用 //他在后面的拦截会被使用，很重要     StreamAllocation streamAllocation = new StreamAllocation(client.connectionPool(), createAddress(request.url()), call, eventListener, callStackTrace); this.streamAllocation = streamAllocation; int followUpCount = 0;//重试次数，默认最大重试次数是20     Response priorResponse = null;//这个priorResponse记录之前一次请求返回的Response while (true) { if (canceled) { //如果已经取消该请求，立即释放streamAllocation，结束该请求，后面的拦截器都不会执行了         streamAllocation.release(); throw new IOException("Canceled"); }        Response response;//这个Resonse记录每次请求返回的response, //就是根据response的返回结果判断是否需要重试的       boolean releaseConnection = true;//是否要释放connection的标志位 try {         response = realChain.proceed(request, streamAllocation, null, null);//调用下一个拦截器获得Response         releaseConnection = false; } catch (RouteException e) { //如果捕捉到路由异常 // The attempt to connect via a route failed. The request will not have been sent. if (!recover(e.getLastConnectException(), streamAllocation, false, request)) { throw e.getFirstConnectException(); }         releaseConnection = false; continue;//尝试重新请求 } catch (IOException e) { //捕捉到IO异常 // An attempt to communicate with a server failed. The request may have been sent.         boolean requestSendStarted = !(e instanceof ConnectionShutdownException); if (!recover(e, streamAllocation, requestSendStarted, request)) throw e;         releaseConnection = false; continue;//尝试重新请求 } finally { //最后释放所有的资源 // We're throwing an unchecked exception. Release any resources. if (releaseConnection) {           streamAllocation.streamFailed(null);           streamAllocation.release(); } } // Attach the prior response if it exists. Such responses never have a body. //不保存响应体，所以body为null if (priorResponse != null) { //保存最新的Response,第一次执行请求这个if判断不会被执行         response = response.newBuilder() .priorResponse(priorResponse.newBuilder() .body(null) .build()) .build(); }        Request followUp;//如果followUp为空表示没必要进行重试，直接返回response try { //followUpRequest是判断有没有必要进行重试的方法，他需要根据response进行判断得到followUp         followUp = followUpRequest(response, streamAllocation.route()); } catch (IOException e) {         streamAllocation.release(); throw e; } if (followUp == null) { //如果followUp为空表示没必要进行重试，直接返回response         streamAllocation.release(); return response; //下面的都不会被执行了 } closeQuietly(response.body()); if (++followUpCount > MAX_FOLLOW_UPS) { //超过重试次数，释放资源，不再重试，抛出异常         streamAllocation.release(); throw new ProtocolException("Too many follow-up requests: " + followUpCount); } if (followUp.body() instanceof UnrepeatableRequestBody) { //如果是不能重复请求的请求体，就直接释放连接         streamAllocation.release(); throw new HttpRetryException("Cannot retry streamed HTTP body", response.code()); } if (!sameConnection(response, followUp.url())) { //比较是否是同一个host,port,schema         streamAllocation.release();//如果不是，先释放原来建立好的连接         streamAllocation = new StreamAllocation(client.connectionPool(), createAddress(followUp.url()), call, eventListener, callStackTrace); //获取最新followUp请求中指定的url建立流 this.streamAllocation = streamAllocation;//重新赋值 } else if (streamAllocation.codec() != null) { throw new IllegalStateException("Closing the body of " + response             + " didn't close its backing stream. Bad interceptor?"); }        request = followUp;//将请求改为重定向最新的请求       priorResponse = response;//记录最新的Response } }

1.2 工作原理

这些分析需要看懂才能明白RetryAndFollowUpInterceptor拦截器的工作原理！

看完源代码以后，我们来简单梳理一下RetryAndFollowUpInterceptor的工作原理。

原理：当RetryAndFollowUpInterceptor拦截器指定intercept方法时，第一次执行时，会调用后面的拦截器链获得返回的Response，然后根据Response中的信息，最主要的就是状态码，重试次数，请求体是否允许重复请求，决定是否需要进行重新连接，既然要进行重新请求，那么有可能会对url进行改变，如果改变就不能使用之前建立好的stream,需要重新建立。根据状态码判断如果不需要重新连接，则该请求直接返回Response，工作结束！

2.BridgeInterceptor

当在RetryAndFollowUpInterceptor拦截器中调用拦截器链的执行方法时，将会被执行的就是BridgeInterceptor拦截器，先从源码分析再讲解原理.

2.1 源码分析

根据之前说的BridgeInterceptor的作用，就是把用户传来的Request转换成符合网络请求格式的Request,把网络返回的Response（可能被压缩过）转换成用户可以用的Response,所以该拦截器就是对Request和Response做操作

 @Override   public Response intercept(Chain chain) throws IOException {     Request userRequest = chain.request();     Request.Builder requestBuilder = userRequest.newBuilder(); //requestBuilder就是根据用户传来的Request创建一个请求构造，添加上一些请求字段     RequestBody body = userRequest.body();//获取请求体，一般请求体不需要被改变 if (body != null) {       MediaType contentType = body.contentType(); if (contentType != null) { //添加Content-type字段         requestBuilder.header("Content-Type", contentType.toString()); } long contentLength = body.contentLength(); if (contentLength != -1) { //添加content-length字段         requestBuilder.header("Content-Length", Long.toString(contentLength));         requestBuilder.removeHeader("Transfer-Encoding"); } else { //添加传输编码字段         requestBuilder.header("Transfer-Encoding", "chunked");         requestBuilder.removeHeader("Content-Length"); } } if (userRequest.header("Host") == null) { //添加host字段       requestBuilder.header("Host", hostHeader(userRequest.url(), false)); } if (userRequest.header("Connection") == null) { //允许长连接       requestBuilder.header("Connection", "Keep-Alive"); } // If we add an "Accept-Encoding: gzip" header field we're responsible for also decompressing // the transfer stream.         boolean transparentGzip = false; //是否支持Gzip压缩的标志位 if (userRequest.header("Accept-Encoding") == null && userRequest.header("Range") == null) { //如果用户的接受编码为空，也就是对接受Response的编码没有要求，则允许Gzip压缩编码       transparentGzip = true;       requestBuilder.header("Accept-Encoding", "gzip"); }      List<Cookie> cookies = cookieJar.loadForRequest(userRequest.url()); //支持cookies if (!cookies.isEmpty()) {       requestBuilder.header("Cookie", cookieHeader(cookies)); } if (userRequest.header("User-Agent") == null) { //指定发起请求的平台，引擎，版本号等信息       requestBuilder.header("User-Agent", Version.userAgent()); } //对Reuqest的设置好了，再接着调用下一个拦截器获得Response,然后对Response进行处理返回给用户     Response networkResponse = chain.proceed(requestBuilder.build());      HttpHeaders.receiveHeaders(cookieJar, userRequest.url(), networkResponse.headers()); //着手根据网络返回的Response构建返回给用户的Response     Response.Builder responseBuilder = networkResponse.newBuilder() .request(userRequest); if (transparentGzip         && "gzip".equalsIgnoreCase(networkResponse.header("Content-Encoding")) && HttpHeaders.hasBody(networkResponse)) { //这是个复杂的判断逻辑，首先就是我们允许了Gzip编码， // 第二个是响应的内容编码确实Gzip编码，第三个就是Response有返回体， //任何一个条件不成立都没必要执行这一步       GzipSource responseBody = new GzipSource(networkResponse.body().source());       Headers strippedHeaders = networkResponse.headers().newBuilder() .removeAll("Content-Encoding") .removeAll("Content-Length") .build(); //上面的这一系列操作，就是移除一系列头部，只返回重要信息给用户       responseBuilder.headers(strippedHeaders);       String contentType = networkResponse.header("Content-Type");       responseBuilder.body(new RealResponseBody(contentType, -1L, Okio.buffer(responseBody))); } //返回最后处理好的Response,retryAndFollowUpInterceptor就是根据此结果 //判断是否要重试。 return responseBuilder.build(); }

2.2 工作原理

BridgeInterceptor原理：对用户传入的请求做处理，在程序员编写代码时只需要指定Url和请求体，但是事实上，一个完整的请求报文远不止这些信息，BridgeInterceptor帮我们做了这些事，添加各种请求报文所需要的字段，然后再传递给下一个拦截器去执行。对于得到的返回结果Response，其内容可能经过了Gzip压缩，所以BridgeInterceptor帮我们做了解压缩。这像极了爱情！！！

3.CacheInterceptor

CacheInterceptor的的作用就是缓存网络请求，注意只能缓存GET类型的请求。他是怎么实现缓存的呢？看一下源码一探究竟。

3.1 源码解析

@Override  public Response intercept(Chain chain) throws IOException { //cache是构建缓存拦截器时指定的 //根据Request的url判断是否有缓存     Response cacheCandidate = cache != null         ? cache.get(chain.request()) : null; long now = System.currentTimeMillis(); //缓存策略，会有详细介绍 //当有请求到达时，需要判断该请求是否有缓存，该缓存是否可用，依次构建策略     CacheStrategy strategy = new CacheStrategy.Factory(now, chain.request(), cacheCandidate).get(); //如果networkRequest==null,就调用缓存     Request networkRequest = strategy.networkRequest; //如果cacheResponse==null,就是用网络请求     Response cacheResponse = strategy.cacheResponse; //如果两者都为null，则返回fail if (cache != null) { //这里的cache是在我们创建OkhttpClient时指定的       cache.trackResponse(strategy); } if (cacheCandidate != null && cacheResponse == null) { //如果有缓存，但是缓存不可用，关闭 closeQuietly(cacheCandidate.body()); // The cache candidate wasn't applicable. Close it. } // If we're forbidden from using the network and the cache is insufficient, fail. if (networkRequest == null && cacheResponse == null) { //如果网络不可用并且缓存不可用，直接返回失败 return new Response.Builder() .request(chain.request()) .protocol(Protocol.HTTP_1_1) .code(504) .message("Unsatisfiable Request (only-if-cached)") .body(Util.EMPTY_RESPONSE) .sentRequestAtMillis(-1L) .receivedResponseAtMillis(System.currentTimeMillis()) .build(); } // If we don't need the network, we're done. if (networkRequest == null) { //如果不需要网络，缓存可用，返回缓存 return cacheResponse.newBuilder() .cacheResponse(stripBody(cacheResponse)) .build(); } //到了这一步，说明网络可用，并且没有可用的缓存     Response networkResponse = null; try { //调用下一个拦截器获取Response       networkResponse = chain.proceed(networkRequest); } finally { // If we're crashing on I/O or otherwise, don't leak the cache body. if (networkResponse == null && cacheCandidate != null) { closeQuietly(cacheCandidate.body()); } } // If we have a cache response too, then we're doing a conditional get. if (cacheResponse != null) { //如果该请求之前有缓存 if (networkResponse.code() == HTTP_NOT_MODIFIED) { // 说明缓存还是有效的，则合并网络响应和缓存结果。同时更新缓存； //并且从网络请求得到的response的响应码，更新缓存         Response response = cacheResponse.newBuilder() .headers(combine(cacheResponse.headers(), networkResponse.headers())) .sentRequestAtMillis(networkResponse.sentRequestAtMillis()) .receivedResponseAtMillis(networkResponse.receivedResponseAtMillis()) .cacheResponse(stripBody(cacheResponse)) .networkResponse(stripBody(networkResponse)) .build();         networkResponse.body().close(); // Update the cache after combining headers but before stripping the // Content-Encoding header (as performed by initContentStream()).         cache.trackConditionalCacheHit();//更新命中率等一些操作         cache.update(cacheResponse, response);//更新缓存 return response;//返回结果 } else { closeQuietly(cacheResponse.body()); } }      Response response = networkResponse.newBuilder() .cacheResponse(stripBody(cacheResponse)) .networkResponse(stripBody(networkResponse)) .build(); if (cache != null) { if (HttpHeaders.hasBody(response) && CacheStrategy.isCacheable(response, networkRequest)) { // Offer this request to the cache.         CacheRequest cacheRequest = cache.put(response); //这一步是真正的向缓存中添加Response return cacheWritingResponse(cacheRequest, response); } if (HttpMethod.invalidatesCache(networkRequest.method())) { try {           cache.remove(networkRequest); } catch (IOException ignored) { // The cache cannot be written. } } } return response; }

CacheInterceptor的源码有点乱，需要多看几遍，这里在说一下缓存策略以及缓存的存取

缓存策略作用的描述

Given a request and cached response, this figures out whether to use the network, the cache, or  both.

给定一个请求和缓存的Response，他能够帮助我们决定是否使用网络，使用缓存或者都是。

重要代码展示：如何通过传入请求和缓存得到策略的

 private CacheStrategy getCandidate() { // No cached response. if (cacheResponse == null) { //如果没有缓存，则进行网络请求 return new CacheStrategy(request, null); } // Drop the cached response if it's missing a required handshake. if (request.isHttps() && cacheResponse.handshake() == null) { //如果是https请求并且握手信息丢失，也需要进行网络请求 return new CacheStrategy(request, null); } // If this response shouldn't have been stored, it should never be used // as a response source. This check should be redundant as long as the // persistence store is well-behaved and the rules are constant. if (!isCacheable(cacheResponse, request)) { //判断请求是否可以被缓存，如果不可以，直接使用网络 return new CacheStrategy(request, null); }      CacheControl requestCaching = request.cacheControl(); if (requestCaching.noCache() || hasConditions(request)) { return new CacheStrategy(request, null); }        CacheControl responseCaching = cacheResponse.cacheControl(); //从这里开始 long ageMillis = cacheResponseAge(); long freshMillis = computeFreshnessLifetime(); if (requestCaching.maxAgeSeconds() != -1) {         freshMillis = Math.min(freshMillis, SECONDS.toMillis(requestCaching.maxAgeSeconds())); } long minFreshMillis = 0; if (requestCaching.minFreshSeconds() != -1) {         minFreshMillis = SECONDS.toMillis(requestCaching.minFreshSeconds()); } long maxStaleMillis = 0; if (!responseCaching.mustRevalidate() && requestCaching.maxStaleSeconds() != -1) {         maxStaleMillis = SECONDS.toMillis(requestCaching.maxStaleSeconds()); } //到这里结束，就是为了判断缓存是否过期，具体细节无需要关注。 if (!responseCaching.noCache() && ageMillis + minFreshMillis < freshMillis + maxStaleMillis) {         Response.Builder builder = cacheResponse.newBuilder(); if (ageMillis + minFreshMillis >= freshMillis) {           builder.addHeader("Warning", "110 HttpURLConnection "Response is stale""); } long oneDayMillis = 24 * 60 * 60 * 1000L; if (ageMillis > oneDayMillis && isFreshnessLifetimeHeuristic()) {           builder.addHeader("Warning", "113 HttpURLConnection "Heuristic expiration""); } return new CacheStrategy(null, builder.build()); } // Find a condition to add to the request. If the condition is satisfied, the response body // will not be transmitted. //流程走到这，说明缓存已经过期了 //添加请求头：If-Modified-Since或者If-None-Match //etag与If-None-Match配合使用 //lastModified与If-Modified-Since配合使用 //前者和后者的值是相同的 //区别在于前者是响应头，后者是请求头。 //后者用于服务器进行资源比对，看看是资源是否改变了。 // 如果没有，则本地的资源虽过期还是可以用的       String conditionValue; if (etag != null) { //默认是null的         conditionName = "If-None-Match";         conditionValue = etag; } else if (lastModified != null) { //The last modified date of the cached response, if known.         conditionName = "If-Modified-Since";         conditionValue = lastModifiedString; } else if (servedDate != null) {         conditionName = "If-Modified-Since";         conditionValue = servedDateString; } else { return new CacheStrategy(request, null); // No condition! Make a regular request. }        Headers.Builder conditionalRequestHeaders = request.headers().newBuilder();       Internal.instance.addLenient(conditionalRequestHeaders, conditionName, conditionValue);        Request conditionalRequest = request.newBuilder() .headers(conditionalRequestHeaders.build()) .build(); return new CacheStrategy(conditionalRequest, cacheResponse); }

缓存策略并不复杂，还有缓存的存取采用的是DiskLru,根据url的md5的hex值作为键去存取，想要深入的可以看一下DiskLruCahce的源码。

3.2 工作原理

原理：底层是基于DiskLruCache，对于一个请求，
1.没有缓存，直接网络请求；
2.如果是https，但没有握手，直接网络请求；
3.不可缓存，直接网络请求；
4.请求头nocache或者请求头包含If-Modified-Since或者If-None-Match，则需要服务器验证本地缓存是不是还能继续使用，直接网络请求；
5.可缓存，并且ageMillis + minFreshMillis < freshMillis + maxStaleMillis（意味着虽过期，但可用，只是会在响应头添加warning），则使用缓存；
6.缓存已经过期，添加请求头：If-Modified-Since或者If-None-Match，进行网络请求；

4.总结

剩下两个拦截器会在下一篇博客讲解，最后还会有个对Okhttp总体的整理和相关的面试题！
